Introduction of Farm Silo
Storage Materials: Wheat, Corn, Soybean, Paddy, Sorghum, peanut, Seed, etc.
Storage Capacity: 100-10000tons
Silo Type: Galvanized Corrugated Bolted Silo
Application: Farm.
Silo Bottom Type: Conical Bottom, Flat Bottom
Auxiliary System: Grain receiving System, Pre-cleaning System, Dust Collecting System, Drying System, Feeding and Conveying System, and Truck Loading, etc.
As a grain silo manufacturing project company with over decade years experiences, SRON provides customized and EPC services according to different functional needs, site and climate conditions and investment plans of each client's project.
If you are interested in our farm storage silo system or would like to know specific quote or details, please click here，we will contact with you as soon as possible.
.jpg)
Farm Silo Introduction
Farm silos serve two main purposes: storing grain and providing feed for livestock. Grain stored in farm silos is often used to make animal feed. This feed can be fed directly to animals or used to make other products, such as ethanol. Farm silos can also be used to store grain for human consumption. Grain and feed can only be put into steel silo after reaching proper humidity, otherwise, they will become moldy.
Using steel silos to store feed and grain in farms can provide long-term, good mechanical ventilation, dry and closed conditions, and strict dust removal, explosion-proof, moisture-proof and other measures can achieve the ideal state of feed and grain storage in farms. At the same time, the use of steel silos to store feed and grain can also improve work efficiency, standardize work processes, improve enterprise management levels, ensure the stability of feed and grain storage, and reduce labor input.
Clients can directly contact with our salesmen and tell us about your needs for farm silo system, such as silo type, capacity, the choice of accessories, etc. Our engineers can design the project drawings of farm silo system for you and discuss any problems that may occur before construction and solve them.
Farm Silo System Process
The whole farm silo system includes grain receiving, pre-cleaning, dust collecting, grain drying, feeding and conveying, silos and truck loading,etc. And there are ventilation system, grain monitoring system, material level monitoring and other auxiliary systems for support. The schematic diagram is as follows:
.jpg)
Ventilation System The roof of farm silo is installed natural ventilation window, induced draft fan, and the cone bottom of farm silo is installed blower to divert air to the silo for circulation, which can protect the grain from moisture, greatly ensure the quality of grain in farm silo.
Temperature and Humidity Measurement System, Grain Monitoring System The system allows clients to grasp the temperature and humidity in the farm silo anytime and anywhere, control the situation in the silo.
Material Level Monitoring System The material level device can monitor the empty and full degree of steel silo. When the grain is about to fill the entire steel silo, the material level device sends an alarm signal to effectively control the grain in the silo.
Features of SRON Farm Silo System
The capacity of steel silos is generally between 20-10,000 tons, which can meet the storage needs of large and medium-sized farms. And the steel silo sealing performance is good, the construction speed is fast, the material level measurement technology is advanced, in line with the current trend of farm mechanization production.
1.Short Construction Period
On-site construction, installation of steel silo roof on the ground, and molding of special construction equipment. The assembly of bolted steel silo is simple and fast, and all its parts are connected by bolts, thus shortening the construction period.
2.Safe Grain Storage
Farm steel silo is easy to realize mechanization. In farm silo, it can be conveniently equipped with equipment such as feeding, discharging, cleaning, ventilation, temperature measurement, and detecting the fullness of the silo to achieve the purpose of safe grain storage.
3.Thermal Insulation Air-tight Treatment
It is convenient to deploy thermal insulation treatment and air-tight treatment, air-tight thermal insulation steel silo is conducive to fumigation and controlled atmosphere storage, and also has good insect and rat proof performance.
4.Long Service Life
The maintenance cost of farm silo is low, and the service life is suitable, which can generally reach about 30 years.
5.Less Investment
20-30% less costs over concrete silos, greatly saving investment. The construction is very fast, the investment return is fast, and the return rate is high.
6.High Automation
The entire silo system is controlled by a DDG control cabinet or a programmable PLC analog flow chart, and the relevant processes are fully automatic, which can achieve a high degree of mechanization and automation, high production efficiency.
.jpg)
Precaution When Using Farm Silo
1. The silo body must be kept safe at all times. If the silo body is in a humid environment for a long time, the surface of steel silo will be rusted. On the one hand, the rusty surface will shorten the service life of steel silo. On the other hand, rust will also affect the quality of the bulk materials in storage silo.
2. The grain and feed can only be put into the steel silo after reaching proper humidity. Only when the grain is dry enough can the grain and feed be put into the silo, otherwise, the grain will become moldy.
3. It is best to regularly check the operation of the dust collector, fan and the sealing of the silo. Inspecting these components not only prolongs the life of farm silo, but also ensures the safety of grain and farm silo.
4. The silo must be operated in accordance with the instructions. Proper operation can help prolong the service life of steel silo and keep it safe. Especially when choosing the installation site, the appropriate space should be
.jpg)
Price of SRON Farm Silo System
The price of SRON farm silos is the most competitive. Advanced technology enables our company to produce high quality farm storage silos at reasonable cost. SRON has adopted some advanced technologies to improve the performance quality of steel silo. China's steel industry is developing rapidly, and the quality of steel is good, so our grain silos are of high quality and relatively low prices. If you are interested in our farm silo or want to know more details about the whole farm silo storage system, please contact us.
Farm Silo Parameters
SRON Farm Silo Specifications:
|
50ton |
100ton |
200ton |
300ton |
500ton |
800ton |
1000ton |
1500ton |
| Silo Bottom |
Hopper 45° |
Hopper 45° |
Flat |
Hopper 45° |
Flat |
Hopper 45° |
Flat |
Hopper 45° |
Flat |
Hopper 45° |
Flat |
Hopper 45° |
Flat |
Hopper 45° |
Flat |
| Model |
TCZK04503 |
TCZK05504 |
TCK05505 |
TCZK06406 |
TCK06407 |
TCZK07307 |
TCK07308 |
TCZK08210 |
TCK08211 |
TCZK10010 |
TCK10011 |
TCZK11011 |
TCK11012 |
TCZK12811 |
TCK12813 |
Diameter(m)
|
4.583 |
5.5 |
5.5 |
6.417 |
6.417 |
7.334 |
7.334 |
8.25 |
8.25 |
10.084 |
10.084 |
11 |
11 |
12.834 |
12.834 |
| Rings |
3 |
4 |
5 |
6 |
7 |
7 |
8 |
10 |
11 |
10 |
11 |
11 |
12 |
11 |
13 |
| Volume(m3) |
76 |
142 |
147 |
273 |
275 |
415 |
411 |
718 |
704 |
1110 |
1067 |
1452 |
1384 |
2039 |
2052 |
Please feel free to give your inquiry in the form below. We will reply you in 24 hours.
